HDM-CD120

Model
HDM-HGP 125/30

Engine
Model : Vikyno
Max. Power : 12.5 hp @ 2400 rpm

Pump Piston
Size : 80 mm
Type : Single
Max. Stroke : 60 stroke/min
Max. Flow Rate : 125 liters/min
Max. Pressure : 30 bar

Dimension*
Width : 1200 mm
Length : 1600 mm
Height : 1100 mm
Weight* : 650

Weight*
650 kg

Model
HDM-HGP 125/60

Engine
Model : Vikyno
Max. Power : 16.5 hp @ 2400 rpm

Pump Piston
Size : 100 mm
Type : Single
Max. Stroke : 60 stroke/min
Max. Flow Rate : 125 liters/min
Max. Pressure : 60 bar

Dimension*
Width : 1300 mm
Length : 1600 mm
Height : 1200 mm

Weight*
730 kg

Model
: HDM-HGP 250/30

Engine
Model : Vikyno
Max. Power : 22 hp @ 2200 rpm

Pump Piston
Size : 80 mm
Type : Single
Max. Stroke : 60 stroke/min
Max. Flow Rate : 250 liters/min
Max. Pressure : 30 bar

Dimension*
Width : 1200 mm
Length : 2100 mm
Height : 1100 mm

Weight*
820 kg

Model
HDM-HGP 250/60

Engine
Model : Vikyno
Max. Power : 25 hp @ 2400 rpm

Pump Piston
Size : 100 mm
Type : Single
Max. Stroke : 60 stroke/min
Max. Flow Rate : 250 liters/min
Max. Pressure : 60 bar

Dimension*
Width : 1300 mm
Length : 2100 mm
Height : 1200 mm

Weight*
870 kg

Model
HDM-HGP 800/70

Engine
Model : Cummins
Max. Power : 116 hp @ 2500 rpm

Pump Piston
Size : 100 mm
Type : Double
Max. Stroke : 75 stroke/min
Max. Flow Rate : 863 liters/min
Max. Pressure : 70 bar

Dimension*
Width : 1800 mm
Length : 2100 mm
Height : 1200 mm

Weight*
1350 kg

*All dimensions and weights are approximate.
